Martin F. Schlögl's r/c models - helicopter

Hughes 500 fuselage (for TRex 450) - TRex 450 - Walkera 4G6 - Blade mSR - PicooZ Atom

Align/Robbe T-Rex 450 SE v2

carbon/aluminum r/c 3D helicopter length: 660 mm height: 230 mm weight: 880 g (510 g without battery) main rotor diameter: 700 mm blade length: 325 mm controls: pitch, roll, yaw, collective pitch, throttle, gyro, lights head speed: 2800 rpm engine: brushless Align 430XL, 3700 KV, 350 W esc: Robbe Roxxy BL-Control 940-6 40 A battery: 3S LiPo 11.1 V, 2150 mAh, 25C receiver: Spektrum AR8000 2.4 GHz DSMX telemetry: Spektrum TM1000 gyro: Align 3G FL760 swashplate servos: HiTec HS-5065MG yaw servo: Align DS-420 main blades: carbon Blattschmied X-Tro
	built February 2009 maiden flight 2009-04-11 fuselage: Heli Artist Hughes (MD) 500D scale fuselage LED light system length 640 mm height 310 mm weight 1350 g (980 g without battery) August 2012: deconstruction to original trainer, because of unrecoverable vibrations

Kyosho 20102RS Minium AD Caliber 120 R22 (Type R)

miniature r/c helicopter length: 180 mm weight: 30 g main rotor diameter: 198 mm controls: pitch, roll, yaw, throttle (fixed pitch) transmitter: Perfex 2.4 GHz, 4 proportional channels, throttle stick spring removed and tweaked to full travel two electric engines (main and tail rotor) proprietary "all-in-one" electronics (4 channel 2.4 GHz receiver, two esc's, gyro), and two sub-micro servos battery: 1S LiPo 3.7 V, 150 mAh

purchased July 2009 very small and a bit nervous to steer sold 2009

E-Flite EFLH3080 Blade mSR

miniature r/c helicopter length: 190 mm weight: 28 g (25 g without battery) main rotor diameter: 180 mm controls: pitch, roll, yaw, throttle (fixed pitch) head speed: 2300-3100 rpm two electric engines (main and tail rotor) Spektrum EFLH3001 "all-in-one" electronics (5 channel 2.4GHz DSM2 receiver, gyro, two esc's, two onboard-servos) engine: coreless brushed battery: 1S LiPo 3.7 V, 160 mAh "glow in the dark" parts

purchased November 2009 sold 2017

Silverlit 85858 PicooZ Atom

miniature r/c helicopter length: 110 mm weight: 7 g main rotor diameter: 95 mm controls: yaw, throttle (fixed pitch) two electric engines (main and tail rotor) transmitter: proprietary infrared control, 2 proportional channels battery: 3.7 V, 40 mAh
	purchased March 2010 maiden flight 2010-03-04 sold 2010

Walkera 4G6

miniature r/c 3D helicopter length: 290 mm weight: 97 g (83 g without battery) main rotor diameter: 302 mm controls: pitch, roll, yaw, collective pitch, throttle, gyro head speed: 3200 rpm engine: brushless Walkera WK-WS-12-005, 10000 KV selfmade engine cooler (bended piece of an old 486 cpu heat sink) esc: Walkera WK-WST-10A-L3 receiver/gyro: Walkera RX2609 2.4 GHz battery: 1S LiPo 3.7 V, 650 mAh servos: Walkera 3x WK-02-1, 1x WK-03-3

purchased June 2010 in used condition (needing some repairs) "spectrumization": receiver: stripped-down Spektrum AR6100, 6 channels, 2.4 GHz DSM2     removing the servo connectors halves the weight     the electrolytic capacitor could also be removed (I didn't...)     soldering the Walkera servo-plugs to the AR6100 was very tricky,     better connect the wires directly, or use an AR6300 I recycled the original gyro:     the Walkera RX2609 brick consists of two boards, the receiver and the gyro.     connected with 7 soldering points, easy to separate.     The receiver can also be recycled, and modified further to use all 6 channels, see Rob's hangar     picture of my AR6100 with mounted gyro, and labeled pinouts: rx2609gyro_on_stripped_ar6100 voltage booster: LVBoost     converts the 3.x V of the Lipo to constant 5 V to avoid dropouts of the AR6100.

Silverlit 85976 PicooZ Hugo

miniature r/c helicopter length: 100 mm weight: 9 g main rotor diameter: 95 mm controls: yaw, throttle (fixed pitch) two electric engines (main and tail rotor) transmitter: proprietary infrared control, 2 proportional channels battery: 3.7 V, 40 mAh
	purchased October 2010 maiden flight 2010-10-25

E-Flite BLH3580 Blade mCP X

miniature r/c 3D helicopter length: 235 mm weight: 46 g (39 g without battery) main rotor diameter: 245 mm controls: pitch, roll, yaw, collective pitch, throttle, gyro head speed: 4400 rpm two electric engines (main and tail rotor) Spektrum BLH3601 "all-in-one" electronics (5 channel 2.4 GHz DSM2 receiver, flybarless gyro, two esc's) servos: 3x Spektrum SPMAS2000LBB 1.5 g Ultra-Micro servo engine: brushed battery: 1S LiPo 3.7 V, 200 mAh Microheli aluminum swashplate selfmade full carbon tailboom, approx. 1 cm longer second mCP X: aluminum swashplate fuselage
	first mCPX purchased March 2011 second mCPX with canopy, purchased Dec 2017, in used condition

Align/Robbe T-Rex 450 Pro v2

carbon/aluminum r/c 3D helicopter length: 635 mm height: 230 mm main rotor diameter: 710 mm blade length: 325 mm controls: pitch, roll, yaw, collective pitch, throttle, gyro, lights head speed: 3000 rpm engine: brushless Align 450MX, 3400 KV, 500 W esc: Robbe Roxxy BL-Control 940-6 40 A battery: 3S LiPo 11.1 V, 2200 mAh, 35C receiver/gyro: Spektrum AR7200BX 2.4 GHz DSMX, integrated MicroBeast telemetry: Spektrum TM1000 swashplate servos: HiTec HS-5065MG yaw servo: Align DS-520 fuselage: Heli Artist Hughes (MD) 500D scale fuselage with LED lights length 640 mm height 310 mm weight ? g (? g without battery)

no own pictures yet, sorry

Skylark infrared controlled helicopter

miniature r/c coaxial helicopter length: 215 mm weight: 45 g main rotor diameter: 192 mm controls: yaw, throttle (fixed pitch), nick (via vertical tail rotor) three electric engines (main and tail rotor) transmitter: proprietary infrared control transmitter: proprietary infrared control, 1 proportional and 2 switching channels battery: 3.7 V
	purchased August 2013 maiden flight 2013-08-31 sold 2014

E-Flite EFLH2400 Blade mCX2

miniature r/c coaxial helicopter length: 200 mm weight: 28 g (25 g without battery) main rotor diameter: 190 mm controls: pitch, roll, yaw, throttle (fixed pitch) two electric engines (each rotor) Spektrum EFLH2401 "all-in-one" electronics (5 channel 2.4 GHz DSM2 receiver, gyro, two esc's and two onboard-servos) engines: coreless brushed battery: 1S LiPo 3.7 V, 120 mAh
	purchased December 2013 in used condition, RTF (with MLP4DSM DSM2 transmitter) maiden flight 2013-12-24 sold 2015

E-Flite EFLH2300 Blade mCX S300

miniature r/c coaxial helicopter, semiscale Schweizer 300C length: 150 mm weight: 28 g (25 g without battery) main rotor diameter: 190 mm controls: pitch, roll, yaw, throttle (fixed pitch) two electric engines (each rotor) Spektrum EFLH1065 "all-in-one" electronics (5 channel 2.4 GHz DSM2 receiver, gyro, two esc's and two onboard-servos) engines: coreless brushed battery: 1S LiPo 3.7 V, 120 mAh
	purchased May 2015 in used condition maiden flight 2015-05-23 sold 2016
